Service Idea >
Strategic Target
Active process, segment synchronization
Professional and efficient, premium value
1.Excellent performance
2.Low fuel consumption
3.High efficiency
4.Suitable for working conditions ofswampland，fishpond，canal, river etc.
Specifications
Features
| YC80S | ||
| Basic parameter | ||
| Machine weightl | kg | 11120 |
| Engine power | kW/rap | 44.4/2100 |
| Standard bucket capacity | m³ | 0.26 |
| Dimensions | ||
| Length of Boom | mm | 4210 |
| Length of Stick | mm | 2650 |
| Length of Pontoon | mm | 5700 |
| Width of Pontoon | mm | 1000 |
| Height of Pontoon | mm | 1300 |
| Width of Chassis | mm | 2950 |
| Operating parameters | ||
| Max.wading depth | mm | 1300 |
| Max.digging height | mm | 8292 |
| Max.dumping height | mm | 6392 |
| Max.digging depth | mm | 4025 |
| Max.Vertical digging depth | mm | 3565 |
| Max.digging radius | mm | 7770 |
| Max.digging radius on ground level | mm | 7510 |
| Fuel tank | L | 151 |
| Hydraulic tank | L | 125 |
| Transportation dimension | ||
| Length | mm | 7650 |
| Width | mm | 2950 |
| Height | mm | 3345 |
